MT320s2 Portable Reference Meter

MT320s2

Portable Reference Meter
Phases: 3
Accuracy class: 0.05

Phases	3
Accuracy class	0.05
Current measurement max.	1000 A (via special current clamps) 12 A (direct measurement)
Voltage measurement max.	300 V
Display	7″ Coloured Touch function
Main functions	CAT IV Actual values, vectorial and curve display Error measurement Measurement of harmonics up to the 40th
Scope of application	On-site measurement with system load Power supply via mains plug or battery pack
Specials	Burden measurement for CT/VT Exchangeable battery pack Further measurement inputs for U (PE-PN) and IN Hardware is expandable modularly I transformer testing (optional) Non-sensitive against interferences (e.g. 150 kHz) Selective power measurement (optional) Supply via mains plug or battery pack
