Features
- Voltage up to 800 V (1200V on request)
- Currents up to 2,250 A
- Power 500 W … 28.8 kW
- Depending on model, temporary overload capacity
- Current, voltage, resistance, power mode
- Dynamic loads
- SCPI programming with measurement function
- Full electronic protection
- Analog measurement outputs for voltage and current
- Analog control input
- MPP tracking
- Dynamic function with synchronized data logging
Operating Modes
The ZS series electronic loads have the four operating modes constant current, voltage, power and resistance. In addition, depending on the operating mode limit values can be set for the maximum permissible current and the minimum permissible voltage.
To increase the resolution for each device, along with the full setting range, a reduced setting of 1/3 of the rated current is available. The load can be preset even without a connected test unit. The display then shows the values directly in amps, ohms, volts or watts.
Dynamic and Control Time
- The inbuilt modulator enables two independently adjustable currents and times from 100 ?s … 1 s. The control speed of the devices can be adjusted to the test unit in three stages (fast – medium – slow).
- Interfaces (optional)
- RS-232 + USB
- GPIB
- Smart-LAN (Ethernet-RS-232 Converter)
- System Interface Cabel or Fiber Optic
- Data Acquisition Tool
- Hardware Expansions (optional)
- Electrically Isolated Analog I/O Interface
- Power I/O Card
- Analog I/O Extension Card
- Temperature Interface
- Castors
- Zero-Volt Option
